Teamtex RANGER SL Mode D'emploi page 33

Installation diagram for group II III
Forward facing use (15-36 kg)
Group 2-3
15-36 kg
From 3 to 12 years
old approx.
ISO FIX
Position the seat forward facing
and in the most upright recline
position, attach the two Isofix
connectors. Use of the support
leg is not necessary.
2
Make sure the vehicle seat belt is tight and not
twisted. Only use the upright position in Groups 2
and 3. Make sure the lap belt sits low across
the pelvis.
13
Remove the infant cushion
and 5-point harness.
With the child in the seat, attach
the vehicle seat belt and guide
the diagonal section of the belt
through the belt guide in the
headrest.
WARNING
1
EN
33
