Rear panel input/outputs
EXTERNAL
75Ω FM ANTENNA
"
A 3.5 mm ( 1 ) FM
/
8
antenna connector.
Connecting an external FM antenna
All manuals and user guides at all-guides.com
The rear panel of your Wave
Bose link
Bose ® link connector
®
Connects to Bose link-
®
enabled Lifestyle systems.
®
The Wave music system power cord includes a built-in FM antenna. If, after adjusting the
position of the power cord, you still experience poor reception, you may connect the system
to an external roof or cable antenna or an FM dipole antenna. An adapter is included for
connecting the system to an external roof or cable antenna, and an external FM dipole
antenna can be ordered through Bose
inside the back cover of this guide.
To connect an external roof or cable antenna using the antenna adapter:
• Plug the 3.5 mm ( 1 ") plug of the antenna adapter into the
/
8
the rear panel of your Wave
• Connect the other end of the adapter to your external roof or cable antenna cable.
Antenna adapter
Note: Connecting the system to an external roof or cable antenna disables the built-in antenna,
and the FM signal will only be received through the external antenna. Disconnecting the external
antenna reactivates the built-in antenna

Connecting Other Equipment

® music system provides connections for external equipment.
AUX IN
AUX IN
"
A 3.5 mm ( 1 ) stereo input
/
8
connector for connecting
external sources.
® Customer Service. See the phone numbers listed
®
music system.
HEADPHONE
"
A 3.5 mm ( 1 ) stereo headphone
/
8
®
connector. The Wave music
system speakers are muted when
headphones are connected.
Ω
connector on
75 FM ANTENNA
Ω
75 FM ANTENNA connector
