Installation Instructions
Install Your Washer
Step 4: Connect the drain hose
Position the other end of the drain hose. It can be positioned in three ways.
A. Over the edge of a wash basin.
Secure the g u i d e t o t h e s i d e o f
the basin wall with a hook or to
t h e t a p w i t h a p i e c e o f s t r i n g
t o p r e v e n t t h e d ra i n h o s e f r o m
moving.
B. In a standpipe
The standpipe must be no shorter
than 32 in. (81cm) and no longer
than 39 in. (100cm).
C. In a laundry tub.
The laundry tub must be no shorter
than 32 in. (81cm) and no higher
than 39 in. (100cm).
Make sure that the connection between the drain hose and the wash basin,
standpipe or laundry tub is not airtight.
WARNING
Step 5: Leveling your washer
See if the washer is level by checking the position of the tub or using a leveling
gauge.
1. Slide the washer into position.
2. Open the lid of the washer, and pour
the water into the tub to just below
the pulsator level.
3. If the washer is level, the pulsator is
positioned at the center of the washer
as shown in the figure above right.
If not, level your washer by turning
the front leveling feet clockwise or
counterclockwise as necessary.
There is ONLY ONE adjustable leg
as right figure on this washer.
WARNING
Standpipe
Hose
Retainer
39 in. Max
Tie
32 in. Min
strap
Laundry tub
Hose
Retainer
39 in. Max
32 in. Min
Tie
strap
Pulsator
Leveling gauge
loosen lock
Adjustable legs
15
Installation Instructions
Install Your Washer
Step 6: Powering your washer
Plug the power cord into a 3-prong, well grounded
60Hz approved electrical outlet protected by a 15-amp fuse
or comparable circuit breaker.
Your washer is grounded through the third prong of the power
cord when plugged into a 3-prong grounded electrical outlet.
Step 7: Running a test cycle
Run a test cycle as follows to check if your washer is properly installed.
1. Load about 6 pounds of laundry into the tub.
2. Press the Power button to turn on your washer.
3. Select the Rinse+Spin cycle by pressing the
and Spin lights.
4. Press the Start/Pause button to start the test cycle.
5. The washer should not rock or vibrate excessively when water is supplied or
when washing or spinning, and should drain well during the spin cycle.
If water leaks while water is being supplied or drained, check the water
connections.
WARNING
If the washer rocks and vibrates excessively, level your washer again.
Step 8: Storing your washer
If you want to store your washer at another location, unplug it, drain any remaining
water from the drain pipe and hook the pipe onto the back of the washer.
Disconnect the water inlet hoses from the faucets and move washer to new location.
120Volt
Function to turn ON the Rinse
