Measuring range of the analogue output modules
The measuring ranges, the states of the LEDs and their meaning are
indicated in the following tables:
Analogue output module 4O, 0...20mA - AC2218
Range
0 ... 20mA
0mA ... 20mA
20.001mA ...
23mA
> 23mA
Analogue output module 4O, 0...10V - AC2219
Range
0 ... 10V
0 ... 10V
10,001V ...
11.5V
> 11.5V
14
PAGE
Units
dec.
0000 ... 20000
20001 ... 23000
> 23000
Units
dec.
0000 ... 10000
10001 ... 11500
11500
Units
hex.
0000 ... 4E20
4E21 ... 59D8
> 59D8
Units
hex.
0000 ... 2710
2711 ... 2CEC
> 2CEC
LED O1...O4
analogue
on
nominal range
on
above nominal
flashes
LED O1...O4
analogue
on
nominal range
on
above nominal
flashes
Meaning
range
outside range
Meaning
range
outside range
