Instructions for installation and use
Name
No. of
items
Interior fittings
1 Bench
1 Bench
1 Bench blinds
1 Foot step panel
2 Foot step feet
2 Foot step struts, 2 x 45° diagonal
1 Stainless foot
1 Backrests
1 Bench screen
1 Heater protection grille
2 Heater protection grille
1 Mounting slats for heater protection grille
2 Mounting slats for heater protection grille
2 Headrest
1 Floor grid
1 Ventilation slit
Glass elements
1 Glass door
1 Glass element with holes for door hinges
1 Glass element
Roof trim slats
1 Roof trim slat
2 Roof trim slats 45°
Accessories
1 U aluminium profile
1 Door handle set wood/stainless steel
1 2 door hinges 8653-02
1 Door magnet, sleeve plate
1 Sauna lighting LED RGBW (pre-assembled)
1 3 Silicon cables: 5 x 2.5 mm²
1 Installation material set
1 Assembly instructions
p. 7/32
Dimensions
195 x 62 x 9 cm
83.5 x 62 x 9 cm
62 x 9 x 2 cm
135 x 62 x 9 cm
60 x 42.5 x 4 cm
48.8 x 8 x 2 cm
83.5 x 6 cm
190 x 26 x 5 cm
195 x 35 x 5 cm
65 x 56 x 4.5 cm
50 x 56 x 4.5 cm
65 x 4.5 x 2 cm
52 x 4.5 x 2 cm
43 x 25 x 7 cm
70 x 55 x 4 cm
52 x 14 x 1.5 cm
191.5 x 59 x 0.8 cm
194.5 x 22.4 x 0.8 cm
194.5 x 22.4 x 0.8 cm
208 x 6 x 4 cm
163 x 6 x 4 cm
66.2 x 1.2 x 1.5 cm
190 cm
