Instructions for installation and use
1.4. BALANCE VIEW SMALL parts list
No. of Name
items
Base frame
2 Base frame
1 Base frame
Wall elements
3 A/A wall element with Multiclip
2 A/A wall element
1 A/A electrical element with Multiclip
2 A/B wall element
1 A/B wall elements with Multiclip
1 A/B ventilation element with Multiclip
1 Element above the door
Roof elements
1 Roof element with LED
1 Roof element, front
1 Roof element, middle
Corner posts
2 90º corner post with groove for glass, with Multiclip
2 90° corner post with groove
Support slats
2 Roof support slat 2 x 45°
2 Roof support slat 2 x 45°
2 Roof cover slats
2 Roof cover slats
3 Bench support slats
2 Mounting slats for bench screen
p. 6/32
Dimensions
150 x 9 x 4 cm
204 x 9 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 58 x 4 cm
192 x 10.1 x 4 cm
191.8 x 48 x 4 cm
191.8 x 48 x 4 cm
191.8 x 48 x 4 cm
202 x 6 x 6 cm
193 x 6 x 6 cm
196 x 4 x 4 cm
148 x 4 x 4 cm
144 x 1.2 x 4 cm
104 x 1.2 x 4 cm
57 x 4 x 4 cm
26 x 4 x 4 cm
