- Page 1 power...
- Page 2 Está a punto de instalar y de utilizar un equipo de alta gama que desempeñará una función esencial en la gestión de energía de su sistema con almacenamiento. El variotrack (vt) es un controlador de carga solar MPPT. Conectado a una batería y a paneles fotovoltaicos, el vt recarga automáticamente las baterías de manera óptima.
- Page 3 Studer disclaims all responsibility and liability for damage, costs or losses resulting from an installation that does not comply with the instructions, a faulty operation or inadequate maintenance. The use of studer equipment is in any case under the responsibility of the customer.
- Page 4 Mounting and installation Storage and content Fixing and dimensions 60°C 84mm -20°C vt 80 min. 200mm min. 50mm Mounting place min. 200mm The batteries should only be installed by qualified personnel. 3.8 – 5.5kg vt 80 cooling fan 205mm 120mm...
- Page 5 Wiring bus termination PV connection • 10mm cable M5, 5Nm vt 40 • 25mm cable M6, 5Nm vt 65 vt 80 2’ Protection device (PV side) Switching device, max solar current • 35A vt 40 / • 60A vt 65 / •...
- Page 6 Multi units and power up Display Display system on – the device is off blink – error, check the manual variotrack MPPT solar charger 35 / 40A 25 / 30A Error Float. 1x Charge 15 / 20A Absor. 2x Equal. 3x...
- Page 7 • Check battery Battery cycles (check manual) manufacturer open seal open no abs synchronized with xtender by default rcc 02/03 variotrack MPPT setting Phas Bulk Assembling Psol 0.22 kW the cooling Ubat 12.1 Vdc 0.11 kWh Displaying real time...
- Page 8 PV input vt 40 vt 65 vt 80 général), le variotrack ne nécessite pas d’entretien particulier. Pour vous PV max voltage 150 Voc (75 Voc @ 12Vdc) débarrasser de ce produit, veuillez utiliser les services de collecte des déchets électriques et observer toutes les obligations en vigueur selon le PV max current lieu d’achat.
- Page 9 Serial Number : Installed by : Date : Signature : Call our specialists +41 27 205 60 80 or visit studer-innotec.com/support Studer Innotec SA rue des Casernes 57 1950 Sion, Switzerland info@studer-innotec.com 4O92 © All rights reserved Studer Innnotec SA – V1.0...
