GCE eclipse 2.S Manuel D'utilisation page 3

4. PACKING LIST
1 piece Helmet equipped with LCD filter
1 piece Headgear complete with sweatband
1 piece Operation manual
5. SPECIFICATION
Optical Class
Filter dimension
View area
Sensing
Light Shade
Dark Shades
Time from light to dark
Time from dark to light
(Delay)
6. CONSTRUCTION AND ASSEMBLY
Construction and assembly scheme. See pic. 1 at the end of this manual.
1
Helmet shell
2
Block nut
3
Outer protection lens
4
Auto Darkening Filter (ADF)
5
Inner protection lens
6
Shade adjustment knob
7 ADF Frame
8
ADF frame lock
7. OPERATION
Assemble the mask as shown in the construction and assembly figure (See pic. 1 at the end of this
manual).
The power of ECLIPSE 2.s helmet is provided by solar cells with one lithium battery. Turning on or off is
automatic controlled by circuit. You can use this helmet at any time you need and take it away after
working without operating any key.
Darkness selection.
Striking the arc, the observing window darkens immediately. At this moment, according to the
technical requirement, the operator adjusts the darkness knob (6) in the direction as shown by the
arrow to select the optimum darkness.
Delay time selection.
By moving the DELAY selector knob (1 0) on the rear of the cartridge, the time taken for the lens to
lighten after welding can be altered from 0,1 ~ 0,9 second.
Turn to MIN : The time the lens lighten after welding changes to be shorter. The shortest time is about
0,1 second depending upon welding point temperature and shade set. This setting is ideal for track
welding or production welding with short welds.
Turn to MAX : The time the lens lighten after welding changes to be longer. The longest time is about 0,9
second depending upon welding point temperature and shade set. This setting is ideal for welding at
high amperage where there is an afterglow from the weld.
1 /1 /1 /2
1 1 0 x 90 x 8 mm
96 x 42 mm
2 sensors
#4
#9 - #1 3
0.1 msec (1 /1 0000 sec)
0,1 -0,9 sec
Sensitivity
Grinding function
Power Supply
Auto power off
UV/IR protection
Operating temperature
Storage temperature
Standards
9
Sensitivity Adjustment
1 0
Delay Adjustment
1 1
Screws for fixing headgear
1 2
Headgear tightness adjusting knob
1 3
Headgear top adjusting stripe
1 4
Headgear angle adjustment
1 5
Sweatband
3/24
Adjustable stepless
Yes
Solar cell + 1 Lithium battery
not replaceable
Yes
up to DIN 1 5
-1 0°C ~ 65°C (1 4°F ~ 1 49°F)
-20°C ~ 80°C (-4°F ~ 1 76°F)
EN379 (Filter) EN1 75 (Helmet)
CE – ANSI Z87.1
EN
