Quadra-Fire OUTFITTER-II Manuel Du Propriétaire page 26

IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for
your appliance please provide model number and serial number. All parts listed in this manual must
be ordered from a dealer.
ITEM
1 Hopper Lid Assembly
Hopper Extension
Handle, Hopper Lid
2 Side Curtain, Left Hand
3 Exhaust Combustion Blower
Gasket, Between Blower Housing and Stove
Gasket, Between Blower Housing and Motor
4 Snap disc, Manual Reset
#5 Door Assembly
5 Door Assembly
5.1 Glass Assembly
5.2 Rope, Door, 3/4" x 84"
5.3 Hinge Pins
5.4 Threaded Handle Assembly Kit
5.5 Handle Black Phenolic Kit
6 Baffle Kit
7 Firepot
8 Igniter Chamber Kit
9 Igniter Kit
10 Control Board
11 Convection Blower
Convection Blower Gasket
Convection Blower Bracket
12 Vacuum Switch
Vacuum Hose, 5/32 ID
Hose, Barb Assembly
13 Side Curtain, Right Hand
14 Dial Control
Wire Harness, Dial Control
15 Hopper Switch
See Following page for additional servcie parts
26
R
Service Parts
DESCRIPTION
5.3
5.4
5.5
8105-804A
COMMENTS
5.1
5.2
Pkg of 2
3 Ft
OUTFITTER-II
Beginning Manufacturing Date: Jul 2022
Ending Manufacturing Date: Active
PART NUMBER
SRV7086-019
PPHE200
SRV200-0110
SRV7086-154
812-4400
SRV240-0812
812-4710
SRV230-0080
SRV8105-021
SRV8105-173
832-1680
433-1590/2
SRV7093-024D
KS-5140-1442
SRV7077-006
SRV7077-003
SRV7077-110
SRV7000-660
SRV8105-050
KS-5020-1052
SRV7081-195
SRV7081-210
SRV7000-531
SRV240-0450
SRV229-0920
SRV7086-153
SRV7080-036
SRV7000-667
SRV7000-612
Stocked
at Depot
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
7/21
02/22
