Arcam rCube Mode D'emploi page 24

Problem
There are no lights lit on the
unit
The power light is flashing red
My rCube is on and an iPod is
docked, it appears to be playing
but I can't hear any sound
The unit responds erratically or
not at all to the remote control
Hum when playing the ' A UX-
in' Analogue input
The iPod is playing a video and
I have connected a display to
one of the video outputs but my
images are not displayed.
The sound is thin and lacking
in bass.
The sound is boomy with too
much bass
Check that...
the rCube rear panel power switch is in the 'on' position.
<
the rCube is in upgrade mode. Insert a USB flash drive with upgrade file to
<
update or turn the power off and back on to reset to normal.
the source is set to play from iPod by pressing the 'iPod' button on the remote or
<
the source button on the top panel until the source LED lights green (indicting
iPod source chosen).
both volume LEDs are not lit. If they are, this indicates that sound is muted. Press
<
the 'MUTE' button on the remote or a volume control button to unmute the
sound.
the rCube is powered on, if it is in standby mode press the P button on the
<
remote to turn it on.
there are fresh batteries in the remote.
<
there is a 'line of sight' (no obstruction) between the remote and the rCube's front
<
panel IR receiving point.
all cables are making good connection. If necessary withdraw the cable from he
<
connector and plug it fully in again (turn the power off before doing this).
the connections inside the source cable connector are not broken or badly
<
soldered.
if the hum originates only when one particular source component connected,
<
check that the source is properly grounded. Check that any aerial cable is ground
isolated. Contact an installation contractor for assistance.
all cables are making good connection. If necessary withdraw the cable from he
<
connector and plug it fully in again (turn the power off before doing this).
the display source is set to display the input the cable is plugged into.
<
the Bass button on the rear panel is not pressed in.
<
Press this button in to add extra bass.
the rCube is too far from a wall.
<
Move the rCube closer to a wall or a corner for more bass output.
the Bass button on the rear panel is pressed in.
<
Set this button to the 'out' position to reduce the bass output.
the rCube is too close to a wall or corner.
<
Move the rCube away from a wall or a corner for less bass output.
E-24
