XR2 Ultimate Micro Radio and ESC/Receiver
The following is an overview of the various functions and adjustments found on XR2 Ultimate Micro radio system for
RC4WD models. It is important to read and understand about all of these functions and adjustments before driving.

1. Transmitter Functions

Description
Steering Wheel
2.4 Antenna
Controls speed (Forward / Brake / Backward)
Throttle Trigger
Adjusts the model to stop when throttle
TH. Trim Dial
Binding indicator and Low Battery indicator
LED indicator
Adjusts the model to run straight when
ST. Trim Dial
Power ON / OFF
Adjusts the maximum steering angle when
ATV
Bind
ST Reverse Switch
TH Reverse Switch
Battery
Compartment Tray
* User should practice the throttle and steering approach
for different cornering at different speeds or road surfaces.

2. Battery Installation

Phillips Screw (M3 x 10)
3. ESC/Receiver Connections
Setup Key
Power ON / OFF
Specifications
Controls direction (Left / Right)
Transmits signal to the model
trigger is at stop position
steering wheel is at center position
Power ON / OFF the transmitter
model turns Left / Right
Allows TX to pair with RX
Reverse direction when operating
steering wheel
Reverse direction when operating
throttle trigger
Contains batteries for powering
the transmitter
Connect to Motor
Connect to Battery
Connect to Servo
Throttle Trim Dial
LED indicator
Steering Trim Dial
Power
ON / OFF
ATV
Bind
Steering
Reverse Switch
Throttle
Reverse Switch
(1) Use a Phillips screwdriver to remove the screw at
the handle and remove the battery compartment cover.
(2) Install the 4x 1.5V AA batteries with correct
polarity as marked on the battery compartment.
(3) Reinstall the battery compartment cover.
Warning: Never disassemble batteries or place the
batteries in a fire or chemical bath.
Battery Disposal: Observe your local regulations for
proper disposal of batteries.
Type
Binding
Lipo
Normal Operation
NiMH
When no signal is received
at RX / ESC
* The LED will remain solid during operation when the
battery type is LiPo and RF signal is received. If user wants
to select NiMH battery, hold the key for 5+ seconds, the
RX/ESC will change to the other battery type. For NiMH, the
LED will continually flash once RF signal is received.
15
Steering Wheel
2.4 ANT
Throttle Trigger
Grip Handle
Battery Compartment Tray
Micro RX/ESC
LED Flashing Quickly
LED Solid On
LED Flashing Slowly
Repeating blink two times quickly
RC4WD 1/18 Gelande II RTR Truck
