Instrument and control functions

Adjusting the headlight beams

The headlight beam adjusting knobs are used
to raise or lower the height of the headlight
beams. It may be necessary to adjust the he-
adlight beams to increase visibility and help
EN
prevent blinding oncoming drivers when car-
rying more or less load than usual.
Obey local laws and regulations when adju-
3
sting the headlights.
To raise the headlight beams, turn the knobs
in direction (A).
To lower the headlight beams, turn the knobs
in direction (B).
B
A
Adjusting the shock absorber assem-
bly
Spring pre-load adjustment
The rear shock absorber is fitted with an
adjustment ring nut for the pre-load of spring
and a return ring nut.
Adjust the spring pre-load as follows:
To increase the spring preload and there by
harden the suspension, turn the adjusting
ring in direction clockwise.
To decrease the spring preload and there by
soften the suspension, turn the adjusting ring
in direction counterclockwise.
At the end of the adjustment, tighten the ring
and ringnut.
1
B
A
1. Return ring nut
2. Spring preload adjusting ring
Adjustment of the hydraulic brake action
in extension
It is possible to adjust the hydraulic brake
action in extension device using the adjust-
ment screw.
Turn it in direction "2" to increase the brake
action; turn it in direction "3" to reduce it.
2
1. Adjusting knob.
2. Increase braking action.
3. Decrease braking action.
NOTICE
To avoid damaging the mechanism, do not
try turning over the maximum or minimum
setting.
Always have the shock absorber adjusted
by a Benelli assistance centre.
3 - 14
1
3 2
