injuries of any kind resulting from such misuse.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or indust-
rial businesses or for equivalent purposes.

4. Technical data

Speed n .............................................8,500 min
0
Cutting circle .......................................... Ø 24 cm
Protection class ................................................III
L sound power level ............................ 88.3 dB
WA
L sound pressure level ......................... 68.3 dB
pA
K uncertainty ................................................. 3 dB
Vibration ..................................................5.8 m/s
K uncertainty .......................................... 2.3 m/s²
Weight ....................................................... 2.2 kg
Sound pressure level
at the operator's ear ............................... 78 dB(A)
K uncertainty ................................................. 3 dB

Important!

The equipment is supplied without batteries and
without a charger is allowed to be used only with
the lithium-ion batteries of the Power-X-Change
series!
Power-X-Change
20 V, 1.5 Ah .............................. 5 lithium-ion cells
20 V, 3.0 Ah ............................ 10 lithium-ion cells
20 V, 4.0 Ah ............................ 10 lithium-ion cells
The lithium-ion batteries of the Power-X-Change
series are allowed to be charged only with the
Power-X charger.
Charging unit
Mains voltage ................... 200-250 V ~ 50-60 Hz
Output
Rated voltage ........................................ 21 V d. c.
Rated current ....................................... 3000 mA
Anl_GAT_E_20_Li_OA_SPK7.indb 21 Anl_GAT_E_20_Li_OA_SPK7.indb 21
GB
The machine noise might exceed 85 dB (A). The
operator will require noise protection measures
if this is the case. The noise is measured in ac-
cordance with EN ISO 11201:2010 and EN ISO
3744:2010. The value of the vibrations emitted by
the handle was determined in accordance with
EN 28662-1:1992.
Important.
The vibration value changes according to the
area of application of the electric equipment and
may exceed the specifi ed value in exceptional
-1
circumstances.
Reduce noise generation and vibration to a
minimum!
•
Use only equipment that is in perfect condi-
tion.
•
Maintain and clean the equipment regularly.
2
•
Adapt your way of working to the equipment.
•
Do not overload the equipment.
•
Have the equipment checked if necessary.
•
Switch off the equipment when not in use.
•
Wear gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.

5. Before putting into operation

The equipment is supplied without batteries
and without a charger.
5.1 Fitting the safety hood (Fig. 3-4)
When fi tting the safety hood (Fig. 1/Item 8) make
sure that the edge guide (Fig. 1/Item 6) is in a po-
sition in which the blade head (Fig. 1/Item 7) does
not obstruct the fi tting. Push the guard hood (Fig.
1/Item 8) in the direction of the arrow onto the
motor housing as shown in Fig. 3. Make sure that
- 21 -
