Elipson IC4 Mode D'emploi page 22

UK
SPECIFICATIONS
Type
Power
Loudspeaker
Frequency response
Sensitivity
Impedance
Crossover frequency
Dimensions
Cut-out dimensions
Weight
IC4
In-ceiling speaker
80W
2-way coaxial
Mid-bass : 4" paper
cone, rubber edge
Tweeter : ¾" silk dome,
orientation 35° to 40° in
all directions
85Hz-20kHz (±3dB)
84dB/1W/1m
8 Ohms
2400 Hz
Ø181 x D92 mm
Ø138 mm
1.1 kg
22
IC6
In-ceiling speaker
100W
2-way coaxial
Mid-bass : 6" paper
cone, rubber edge
Tweeter : ¾" silk dome,
orientation 35° to 40° in
all directions
70Hz-20kHz (±3dB)
87dB/1W/1m
8 Ohms
1950 Hz
Ø230 x D102 mm
Ø200 mm
1.9 kg
IC6ST
In-ceiling speaker
100W
2-way coaxial
Mid-bass : 6" paper
cone, rubber edge
Tweeter : 2x ¾" silk
dome, orientation 35° to
40° in all directions
65Hz-20kHz (±3dB)
83dB/1W/1m
8 Ohms
2200 Hz
Ø230 x D105 mm
Ø200 mm
1.7 kg
