Attaching to Camera

c

Power Management

Use ON/OFF Power Switch to power the flash unit on or
off. Turn off if it will not be used for an extended period of
time. Setting as a master flash, it will turn the power off
automatically after a certain period (approx. 90 seconds)
of idle use. Pressing the camera shutter halfway or
pressing any flash button will wake up the flash unit.
Setting as a slave flash, it will enter sleep mode after a
certain period (adjustable, 60 minutes by default) of idle
use. Pressing any flash button will wake it up.
Disabling Auto Power Off function is recommended
when the flash is used off camera. (C.Fn-APO)
Slave Auto Power Off Timer is set to 60 minutes by
default. Another option "30 minutes" is available. (C.Fn-
Sv APOT, Page 42)
Modus 600RT
a
b
1. Attach the Speedlight
to the camera.
Slip the flash's mounting foot
into the camera's hotshoe all
the way.
2. Secure the Speedlight Push
the release button to rotate
the lock ring on the mounting
foot until it locks in position
to the right.
3. Detach the Speedlight:
a) Push the release button.
b) Rotate the lock ring to
the left until it is loosened.
c) Slide the speedlight off the
camera hotshoe
