Mounting the camera

• When laying electric connections, ensure that
– They are not kinked or twisted
– They do not rub on edges
– They are not laid in sharp edged ducts without protection (fig. 3, page 4)
• Attach the cables securely in the vehicles to prevent tripping hazards. Use cable binders, insu-
lating tape or glue the cables in place.
• Protect every through-hole made in the bodywork against water penetration, e.g. by using a
cable with a sealant and by spraying the cable and the cable sleeve with sealant.
I
NOTE
Do not start sealing the through-holes until all installation work has been finished for the
camera, and the required cable lengths have been established.
7 Mounting the camera
7.1

Tools required

For installation and assembly you will require the following tools:
• Drill bit set (fig. 1 1, page 3)
• Drill (fig. 1 2, page 3)
• Screwdriver (fig. 1 3, page 3)
• Set of ring or open-ended spanners (fig. 1 4, page 3)
• Measuring ruler (fig. 1 5, page 3)
• Hammer (fig. 1 6, page 3)
• Centre punch (fig. 1 7, page 3)
To make and test the electrical connection, the following tools are required:
• Diode test lamp (fig. 1 8, page 3) or voltmeter (fig. 1 9, page 3)
• Crimping tool (fig. 1 10, page 3)
• Insulating tape (fig. 1 11, page 3)
• Cable bushing sleeves, if necessary
To fasten the cables you may require additional cable binders.
7.2 Mounting and connecting the camera
Proceed as shown (fig. a, page 8 to fig. f, page 11).
A
NOTICE! Risk of damage!
Ensure that there is sufficient space on the other side for the drill head to come out
