Parts List - DK2 POWER OPC514 Guide De Montage

MAINTENANCE & STORAGE

PARTS LIST

NO. DESCRIPTION
1 Chassis
2 Wheel axis
3 Wheel
4 Dust cap
5 Anvil adjusting plate
6 Cutter disk base
7 Protective ring
8 Buckle
9 Anvil
10 Emergency stop button base
11 Emergency stop button
12 Rubber mounting plate
13 Rubber chip baffle
14 Feeding hopper
15 In-feed to frame rubber
16 Blades
17 Bearing cover
18 Bearing locating bush
19 Bearing UCFU208
20 Bearing base
21 Cutter disk
22 Pulley locating bush
23 Flat key
24 Pulley
25 Pulley gasket
26 Disk cover
27 Junction plate 1
28 Rotating plate
29 Junction plate 2
30 Handle
31 Handle shaft
32 Spring
33 Handle support
34 Discharge chute
35 Deflector
36 Clamp handle
37 Belt cover
38 Belt
39 Clutch gasket
40 Clutch
41 Engine flat key
QTY. NO. DESCRIPTION
1 42 Clutch locating bush
2
43 Fenders
2
44 KOHLER CH440 Gasoline engine
2
45 Safety chain
1
46 Tow bar
1
47 Coupler
2
48 Jockey wheel
1
49 Hex bolt M10x60
1
50 Flat washer 10
1
51 Lock nut M10
1
52 Hex bolt M12x80
1
53 Flat washer 12
1
54 Lock nut M12
1
55 Split pin 4x45
1
56 Hex slotted nut M24x1.5
2
57 Spring washer 10
1
58 Flat washer 14
2
59 Carriage bolt M10x45
2
60 Hex bolt M12x30
2
61 Hex bolt M12x70
1
62 Hex nut M10
1
63 Hex bolt M8x20
1
64 Flat washer 8
1
65 Lock nut M8
1
66 Spring washer 8
1
67 Hex bolt M10x20
1
68 Hex socket screw M8x45
1
69 Hex nut M8
1
70 Hex bolt M14x45
1
71 Spring washer 14
1
72 Hex bolt M8x25
1
73 Flat washer 6
1
74 Lock nut M6
1
75 Hex bolt M6x16
1
76 Spring washer 6
2
77 Hex bolt M6x20
1
78 Hex bolt M6x25
2
79 Hex bolt M12x165
1
80 Hex bolt M10x30
1
81 Hex bolt 3/8-24x1
1
82 Hex bolt M10x70
QTY. NO. DESCRIPTION
1 83 Hex bolt M14x65
2 84 Hex socket screw M8x16
1 85 Cross head bolt M4x20
2 86 Flat washer 4
1 87 Lock nut M4
1
1
4
17
8
2
28
20
2
2
14
10
4
15
2
1
12
18
6
12
8
3
3
6
8
2
17
13
4
4
11
2
1
1
1
1
QTY.
2
2
2
2
2
OPC514 man. v.210412 | 45
