USING THE SUBWOOFER (SW-P130)

Controls and their functions

1
POWER
ON
2
OFF
3
110V-120V
VOLTAGE
SELECTOR
220V-240V
1
Power indicator
Lights up GREEN when the POWER switch (
pressed in to the ON position and goes off when set to
the OFF position.
* Standby mode
If the POWER switch (
position and the AUTO STANDBY switch (
to the HIGH or LOW position, this indicator lights up
RED when no signal is received by the subwoofer.
2
POWER switch
Press this switch to the ON position to turn on the
power of the subwoofer. When the power of the
subwoofer is on, the power indicator (
panel lights up GREEN. Press this switch again to set
to the OFF position to turn off the power of the
subwoofer.
3
VOLTAGE SELECTOR switch
(For China, Korean and General models)
If the preset setting of the switch is incorrect, set the
switch to the proper voltage range (220V-240V or
110V-120V) of your area.
Consult your dealer if you are unsure of the correct
setting.
WARNING
Be sure to unplug the subwoofer before setting the
VOLTAGE SELECTOR switch correctly.
SUBWOOFER SYSTEM YST SW005
Front panel
Rear panel
VOLUME
0 10
AUTO
STANDBY
HIGH
LOW
OFF
INPUT
/MONO
POWER
ON
OFF
220V-240V VOLTAGE
SELECTOR
110V-120V
2
) is
2
) is pressed in to the ON
4
) is set
1
) on the front
Port
AUTO
STANDBY
4
HIGH
LOW
OFF
5
INPUT
4
AUTO STANDBY (HIGH/LOW/OFF) switch
This switch is originally set to the OFF position. By
setting this switch to the HIGH or LOW position, the
subwoofer's automatic power-switching function
operates as explained on page 10. If you do not need
this function, set to the OFF position.
* Make sure to change the setting of this switch only
when the POWER switch (
5
INPUT terminals
Used to input line level signals from the amplifier.
6
VOLUME control
Adjusts the volume level. Turn the control clockwise to
increase the volume, and counterclockwise to
decrease the volume.
VOLUME
6
0 10
/MONO
2
) is in the OFF position.
9
