Connecting the AC Adapter

WARNING
Only use the AC adapter provided with the unit.
 Ensure that power supply outlet matches with the unit AC's input 
100-240V, 50/60Hz before connection.
1 Insert the AC Adapter into DC IN jack of the unit.
Insert one end of the Power Cord into the end of the AC
2
Adapter and the other end into an electrical outlet only after
all other connections are completed.
18
8
En-

System Overview

Front Panel

1. Handle
2. Docking tray switch (SLIDE TO CLOSE)
Slide the switch to close the docking tray.
3. Source indicator
Lights when one of the sources is selected.
White: iPod mode
Blue:
To AC wall outlet Green: LINE IN mode
4. iPod connector
5. VOLUME indicators
Five level bars will be lighted up/went out one by one when you
increase/decrease the volume. Light fl ashes when the sound is
muting.
6. S.BASS indicator
Lights when the super bass is activated.
None: OFF
Green: Super bass 1
Orange: Super bass 2
Bluetooth mode
