Electrical connection

Connect the plugs of the sensors to the M12 sockets.
To ensure the protection rating IP 67 you must
• cover the unused sockets with protective caps (E73004)*, tightening
torque 0.6...0.8 Nm.
• use the flat cable end seal (E70413)* if the module is at the end of
the cable line.
*) to be ordered separately
Operation
Avoid build-up of dirt and dust on the upper and lower parts so
that the locking mechanism is not affected.
Check the safe functioning of the unit. LED display:
• LED yellow:
• LED PWR green:
• LED FAULT red is lit:
• LED FAULT red flashes:
Overload and short circuit of the input supply are signalled as
peripheral fault to the AS-i master (version 2.1 or higher).

Technical data

You can download the data sheet from our website at
www.ifm-electronic.com if required.
input switched
AS-i voltage supply o.k.
AS-i communication error, slave does not
participate in the "normal" exchange of
data, e.g. slave address 0
peripheral fault, e.g. sensor supply over-
loaded or shorted
