CAUTION!
Residual risks
Even if you use this electric power tool in
accordance with the instructions, certain
residual risks cannot be eliminated. The
following hazards may arise in connection
with the equipment's construction and
layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear
protection is applied.
3. Health damage caused by hand-arm
vibrations if the equipment is used over a
longer period or is not properly guided and
maintained.
Limit the operating time.
All stages of the operating cycle must be
considered (for example, times in which the
electric tools are switched off and times in which
the tool is switched on but operates without load).

5. Before using the equipment

Be sure to read the following information before
you put the cordless screwdriver into operation:
1. Charge the battery pack with the charger
supplied. An empty battery pack requires
a charging period of approximately 0.5 to 1
hour.
2. Only ever use sharp drill bits and screwdriver
bits which are suitable for the purpose and in
faultless condition.
3. Always check for concealed electric cables
and gas and water pipes when drilling and
screwdriving in walls.
Anl_TE_CD_18_2_Li_SPK7_USA.indb 11 Anl_TE_CD_18_2_Li_SPK7_USA.indb 11
EN

6. Operation

6.1 Torque setting (Fig. 2/Item 1)
Caution! Only ever adjust the setting ring
when the equipment is at a standstill.
The cordless screwdriver is fi tted with a
mechanical torque selector.
The torque for a particular screw size is set with
the setting ring (1). The torque is dependent on a
number of factors:
•
On the type and hardness of the material
involved
•
On the type and length of the screws used
•
On the requirements that the screw
connection has to satisfy
The grating disengagement of the coupling
indicates that the selected torque level has been
reached.
6.2 Drilling (Fig. 2/Item 1)
For drilling purposes, adjust the setting ring for
the torque to the last setting "Drill". In the drill
setting the slip coupling is non-functional. The
maximum torque is available for drilling.
6.3 Changeover switch (Fig. 3/Item 3)
The slide switch above the On/Off switch is for
setting the direction of rotation of the cordless
screwdriver and for preventing the cordless
screwdriver from being switched on inadvertently.
You can select between clockwise and counter-
clockwise rotation. To avoid causing damage to
the gearing, the direction of rotation must only be
changed when the equipment is at a standstill.
When the slide switch is in the middle position,
the On/Off switch is blocked.
6.4 On/Off switch (Fig. 3/Item 4)
Infi nitely variable speed control is possible with
the On/Off switch. The further you push the
switch, the higher the speed of the cordless
screwdriver.
6.5 Switching from speed 1 to speed 2
(Fig. 2/Item 6)
You can work with a higher or lower speed
depending on the position of the selector switch.
Change the gear only when the drill is at a
standstill. If you fail to observe this point, the
gearing may be damaged.
- 11 -
