Neo-Flex™ Universal All-In-One Stand
Weight Capacity:
360˚
CPU size:
(178-356 mm)
2x
Manuel de l'utilisateur
Weight Capacity
for Display:
6 -16 lbs
(2.7 - 7.2 kg)
Total Maximum Weight
Capacity for Stand:
(includes display, CPU,
keyboard and mouse)
7" -14" H
2"-4.5" D
7" -15" W
(50.8-114 mm)
(178-381 mm)
User's Guide
Guía del usuario
Benutzerhandbuch
Gebruikersgids
Guida per l'utente
ユーザーガイド
用户指南
사용자 안내서
37 lbs
(16.7 kg)
1 of 8
