Overview

The Satlook G2 and Satlook HD are Satellite Test Equipment for the professional made in
Sweden. The Satlook G2 can receive DVB-S satellite signals and the Satlook HD can
receive both DVB-S and DVB-S2 satellite signals. Both use advanced demodulators and
can "lock" on transponders using automatic modulation type, symbol rate and FEC
selection. They are easily operated with just three controls and the basic functions are
easy to learn.
The instruments are provided with a 3" LCD which is used to display information such as
signal strength, Spectrum, or Digital information.
The Satlook G2 and Satlook HD can be used to measure satellite signals from two LNBs
at the same time. Signal strength is presented graphically on the LCD display in form of
thermometer scales.
They can also sound a tone which increases in pitch with signal level on an internal
loudspeaker.
They can store 100 positions of Satellite transponder information.
The instruments can easily scan through the memory positions and identify the various
Satellite transponders.
The polarisation of the LNB is switchable by setting the LNB voltage to 13V or 18V and
the High Low band with a 22 kHz signal. The DiSEqC function controls all DiSEqC
accessories such as LNBs, switches, and positioners.
The instruments are supplied with a built-in and rechargeable battery and a carrying case
for protection of the instrument in the installation environment.
