10. Technical Data

NOTE: The data given on the rating plate of
the luminaire apply. You will find the rating
plate on the tube of the luminaire.

10.1 Electrical values

Designation
Nominal voltage
Mains version
Voltage range
SELV version
Power
consumption
Tab. 4: Electrical values.

10.2 Classification

Designation
Protection class
Mains version
Protection class
SELV version
Degree of
protection
Operating mode
Allowed ambient
temperature range
26
Value
230 V AC
22 – 26 V DC
The power consump-
tion is specified on
the rating plate of
the luminaire.
Value
I
III
IP 67
Continuous
operation
-25°C to 40°C
Designation
SELV version
Maximum permis-
sible number of
luminaires in series
(through-wiring)
Mains version
Maximum permis-
sible number of
luminaires in series
(through-wiring)
Tab. 5: Classification.
Technical Data
Value
RL70LE-24 DN
16 luminaires
RL70LE-36 DN
9 luminaires
RL70LE-48 DN
7 luminaires
RL70LE-60 DN
6 luminaires
RL70LE-84 DN
4 luminaires
RL70LE-96 DN
3 luminaires
RL70LE-120 DN
2 luminaires
RL70LE-30 DN
40 luminaires
RL70LE-45 DN
27 luminaires
RL70LE-60 DN
20 luminaires
RL70LE-75 DN
16 luminaires
RL70LE-105 DN
11 luminaires
RL70LE-120 DN
10 luminaires
RL70LE-150 DN
8 luminaires
