battery voltage of 10.8 volts and 12.5 volts the main switch relay can be briefly
(approx. 3 minutes) activated by pressing the button (emergency start
function).

Charging control display

The charging control display lights up (green, fig. 1 pos 6) independently of the
main switch, if the Module B is in mains charging operation and the supply
battery is charged. Charging process see Module B description.

Battery voltage display

By pressing the button (fig. 1 pos. 4) the supply battery voltage on the battery
voltage display (fig. 1 pos. 5) is shown by means of a LED chain.
Green area sufficient battery voltage
Yellow area critical battery voltage
Red area battery voltage too low
The display of the battery voltage is only possible with switched on main
switch.

Fresh water tank display

By pressing the button (fig. 1 pos. 2) the fresh water tank display (fig. 1 pos. 1)
is activated and the tank content level is shown by means of a LED chain in
quarters.
Green area Fresh water tank half full to full (1/2 - 3/4 – 1/1)
Yellow area Fresh water tank almost empty (1/4)
Red area Fresh water tank empty (0)
The fresh water tank display is only possible with switched on main switch.
