Installation and maintenance instructions for
PLATIN XL Rainwater Underground Tank
DN 150:
10000 L Order No. 390006
(390822+371062+371065)
15000 L Order No. 390007
(390823+371062+371065)
DN 100:
10000 L Order No. 390016
(390822+371063+371065)
15000 L Order No. 390017
(390823+371063+371065)
The points described in these
instructions must be observed
under all circumstances. All
warranty rights are invalidated in
the event of non-observance.
Separate installation instructions
are enclosed in the transportation
packaging for all additional articles
purchased from GRAF.
Missing instructions must be
requested from us immediately.
The tank must be checked for any
damage prior to insertion into the
trench under all circumstances.
Missing instructions can be
downloaded on www.graf.info or
can be requested from GRAF.
mail@graf.info
www.graf.info
Table of contents
1. GENERAL NOTES
1.1 Security
1.2 Identification obligation
2. INSTALLATION CONDITIONS
3. TECHNICAL DATA
Technical Data Platin XL / Connection option DN 150 16
3.1
3.2 Overview tanks Platin XL
3.3 Technical Data Platin XL / Connection option DN 100
3.4 Overview tanks Platin XL
4. TANK STRUCTURE
5. INSTALLATION AND ASSEMBLY
5.1 Construction site
5.2 Trench
5.3 Insertion and filling
5.4 Routing connections
6. ASSEMBLING THE TANK DOME TELESCOPIC DOME
SHAFT
6.1 Assembling the tank dome
6.2 Assembling the telescopic dome shaft
6.3 Telescopic dome shaft on which persons may walk
6.4 Telescopic dome shaft over which passenger cars may
drive
6. ASSEMBLING THE TANK DOME AND TELESCOPIC
DOME SHAFT
6.5 Telescopic dome shaft for HGV loading
7. ASSEMBLY OF THE ADAPTER
7.1 Assembling the extension
8. INSPECTION AND SERVICING
13 / 48
14
14
14
15
16
16
17
17
18
18
19
19
21
21
22
22
22
22
22
23
23
24
24
24
