Tank Structure; Installation And Assembly - Graf CARAT Notice De Montage Et D'entretien


Cover

Telescopic dome shaft (can be inclined by 5°)

Profile seal

Tank dome (can be rotated by 360°)

Tank - tank dome seal

Carat underground tank

Baffle

Subsoil

Telescopic dome shaft

Compacted foundation

Surrounding (round-grained gravel, max.
grain size 8/16)
1
info@graf.info
www.graf.info
4.

Tank structure

5.

Installation and assembly




2
4 7
14 / 36
6
1
2
3
4
5
6
Covering layer
Carat underground tank
Concrete layer for surfaces used by
passenger cars / trucks
ß nach DIN 4124
ß according to DIN 4124
5
3
7
ß
> 100 mm
< 300 mm
< 300 mm
< 300 mm
< 300 mm
< 300 mm
< 300 mm
< 300 mm
< 300 mm
> 150 mm
