optional parts and accessories:
power cable: RLLFPC
o
end caps: RLLFEC
o
straight connector: RLLFSC
o
T-connector: RLLFTC
o
L-connector type I: RLLFLC1
o
L-connector type II: RLLFLC2
o
L-connector type III: RLLFLC3
o
aluminium channel for easy installation: RLLFMC
o
power supply: LPS10024R
o
5. Installation
First draw the desired pattern(s) on the installation location. Make sure that the bending radius is not
smaller than 4cm.
When applicable, attach the mounting channels (not incl., order code RLLFMC) according to the
pattern.
When necessary, cut the light rope.
Note: only cut the rope on the markings (one every meter).
Place an end cap (RLLFEC) on the end of the rope. When using outdoor, seal the end cap with
silicone, place a heat-shrinking tube over the end cap and shrink it to ensure water can not enter the
light rope.
Connect the power cable (RLLFPC) to the light rope. When using outdoors, seal the cap with silicone
(both sides), slide a piece of heat-shrinking tube over the connection and shrink it.
Mount the light rope.
Connect the power plug to a suitable mains outlet.
6. Cleaning and maintenance
The electric power supply cables must not show any damage. Have a qualified technician maintain
the device.
Disconnect the device from the mains prior to maintenance activities.
Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
There are no user-serviceable parts, contact your dealer for spare parts if necessary.
7. Technical Specifications
power supply
power consumption
LEDs
RLLF120B
RLLF120G
colour
RLLF120R
RLLF120W
dimensions
length
max. connected strips
weight
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulted from (incorrect) use of this device.
For more info concerning this product and the latest version of this manual, please visit our
website www.hqpower.eu.
The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved.
No part of this manual or may be copied, reproduced, translated or reduced to any electronic medium or
otherwise without the prior written consent of the copyright holder.
01.12.2011
RLLF120x
24Vdc
4.4W/m
80pcs/m
blue
green
red
white (6500K)
16 x 28mm
20m
1 pc (20m) per power supply
±10.5kg
3
©Velleman nv
