ENGLISH
3. DIE REPLACEMENT
(Ref. to Fig. 1)
To replace dies operate as follows:
Upper die (91):
– Press the die release button (17) to release the die and slide the die from the head.
– Insert the replacement die into the head guide and release the button (17) to secure the die.
Lower die (90):
– For ease of operation, advance the main ram (10) by 3-4 mm (0.11 - 0.16 in.).
– Press the die release button (25) to release the die and slide the die from the ram.
– Insert the replacement die into the ram guide and release the button (25) to secure the die.
4. MAINTENANCE
The head is robust and requires very little daily maintenance.
Compliance with the following points should help to maintain the optimum performance of the tool.
4.1) Accurate cleaning
Dust, sand and dirt are a danger for any hydraulic device.
Avoid putting the head on muddy or dusty ground.
Any dirt particles may score the ram and create oil leaks.
Every day, after use, the head must be cleaned with a clean cloth, taking care to remove any residual
particles, especially around the moving parts.
4.2) Replacement of the automatic coupler
Use a 22 mm spanner to unscrew the old coupler:
– Remove the obsolete coupler.
– Carefully clean the thread to remove the old sealant.
– Apply Tefl on tape to the thread.
– Fit the new automatic coupler and tighten to 30 Nm (22 lbf ft).
The oil pressure in the head must always be completely released before disconnecting the head
from the hose.
4.3) Storage
(Ref. to Fig. 2)
When not in use, the head should be stored and transported in the plastic case, to prevent damage.
The plastic case can also accommodate 14 die sets.
Plastic case: VAL P26; Size 445x290x115 mm (17.5x11.4x4.5 in.); weight 1,2 kg (2.65 lbs).
