Man & Machine Its Cool Wireless Mode D'emploi

• Operating Manual • Bedienungsanleitung • Mode d'emploi • Manual de usuario
• Manual do usuário • Istruzioni d'uso • Gebruikshandleiding • Installation
A
USB
on
1 6
4
D
4
5
on
1 6 6
4
Part functions:
EN
Micro USB port: Used to connect Battery charging cable. Cover during
1
washing or rinsing.
Battery charging cable: Used to charge keyboard battery.
2
Port cover: Used to cover Micro USB port during washing or cleaning.
3
Power switch
4
Pairing key
5
LED indicator:
6
Red: keyboard battery is charging, blinking blue: keyboard is trying to
pair, solid blue: keyboard is in paired mode and connected to computer.
USB Dongle: Used to transmit keyboard USB signal to computer.
7
Located on bottom of keyboard.
Installation:
(See figure A.)
Place USB Dongle (7) in computer USB port. Note that each dongle is
different and is paired with it's own keyboard. Turn keyboard on (4).
Wait for keyboard to pair automatically.
If you are using this keyboard in combination with a Man & Machine
wireless C Mouse, you can use one USB dongle to connect both
devices. Once you have installed the first one of our devices and let it
pair automatically, following the pairing procedure to connect the other
device to the same dongle.
Pairing:
(See figure D.)
The keyboard is already paired with the USB dongle that comes with it.
To pair the keyboard with another dongle or to re-pair it with the dongle
it comes with: Hold down the blank key (5) on the left side near the
7 1
5
on
Its Cool Flat Wireless
(Replacement drapes sold separately)
(See figure B.)
B
6
4
7
Ctrl & Alt while turning the keyboard on (4). LED indicator (6) will blink
blue when pairing. If the USB dongle is plugged in, unplug the USB
dongle and plug it back in. Keep the keyboard close to the USB dongle.
Once the keyboard is paired and connected to the PC, the blue LED
indicator will turn soldig blue (6).
Note: The keyboard will not work if it has lost it's pairing. Loss of pairing
is signaled by blinking blue light (6). Follow procedure described above
to restore pairing.
Battery charging:
Use battery charging cable (2). Connect Micro USB connector to
keyboard, connect USB connector to 5V USB charging device or
powered USB computer port. LED indicator (6) will turn red when
charging. The red light will go off when fully charged. Remove and store
cable for future use. Tip: Turn keyboard off when not in use to maximize
battery life. Note: The keyboard will not work if the battery is empty.
Charge timely following procedure described above.
Approved cleaning methods keyboard
•
You can wipe the product with a soft cloth that is non-abrasive such as
a microfiber cloth, a disinfecting wipe, a soft brush similar to a paint
brush in bristle stiffness or a sponge, but not a scourer of any sort.
• You can spray the product with soap and water or an approved
disinfectant.
• You can rinse the product with soap and water or an approved
disinfectant. Before rinsing, remove cable (2) from port (1) and cover
port (1) with cover (3). Make sure cover (3) is fully inserted (See figure C).
Approved cleaning methods drape
• You can wipe, spray or rinse the product as described under "Approved
cleaning methods keyboard"
• You can immerse the product in soap and water or an approved disinfectant
• You can expose the product to Hydrogen Peroxide Vapour (HPV)
• You can sterilize the product in an autoclave or thermo disinfector up to
134 ºC (270 ºF), (tested 200 cycles)
1
2
C
3
3
