4 Operating the electrical
adjustment options
Not every wheelchair has been equipped with
electronic adjustment options. We make a
distinction between four different adjustment
options to the seating system:
• Tilt adjustments
• High/low adjustments
• Backrest adjustments
• Legrest adjustments
4.1 Selecting the desired
adjustment option
1. Switch on the controller
2. Press on the 'mode' button to select the
'adjustment options' mode (E in fi gure 2). The controller will now be in the 'adjustment options'
mode. It is also possible to follow the status.
The joystick is used to select and operate the electronic adjustment options.
3. Move the joystick to the left or the right to select the desired adjustment option. The selected
adjustment option will be visible on the display screen.
4. Moving the joystick forwards and/or backwards will activate the selected electronic adjustment
option (see table 5). Move the joystick forwards or backwards until the desired adjustment option
has been attained.
Tilt adjustment
High/low adjustments
Backrest adjustments
Legrest adjustments
Table 5 Electrical adjustment options
5. To return to the 'drive' mode: Press on the 'mode' button to select the 'drive' mode.
Note: If you adjust the seat height by using the high/low option or use the electrical tilt adjustment 0 -
45°, the speed will be reduced due to safety reasons.
Move joystick backwards
The entire chair will tilt
backwards
The entire chair will be raised
The backrest will tilt backwards
The legrest angle will increase,
the footplate will be raised

Operating the electrical adjustment options | 25

Figure 4 Electrical adjustment options
Move joystick forwards
The entire chair will tilt forwards
The entire chair will be lowered
The backrest will tilt forwards
The legrest angle will decrease,
the footplate will be lowered
