REVERSING THE DOOR SWING
3 REMOVE THE FRESH FOOD DOOR
3.1 Tape the door shut with masking tape.
3.2 Using a 5/16" hex-head socket screwdriver and
a 5/16" open-end wrench, remove the two
screws holding the center hinge to the cabinet.
Lift the center hinge to free its pin from the
socket in the top of the door, and set hinge and
screws aside. Be careful not to lose the center hinge
spacer and washer.
3.3 Remove the tape and tilt the door away from the
cabinet. Lift the door from the pin in the bottom
hinge bracket. (If the plastic washer sticks to the
door bottom, put it back on the hinge.)
3.4 Set the door outside-up on a non-scratching surface.
Installation Instructions
12
(CONT.)
3 REMOVE THE FRESH FOOD DOOR
3.5 Transfer the two screws from the opposite side of the
cabinet to the screw holes vacated by the center
hinge removal.
3.6 Transfer the washer (if your model has one) to the
opposite side.
3.7 Take one of the screws removed in step 2 and start
it in the outermost screw hole on the opposite side.
Do not drive it all the way down—leave enough space
under the screw head for thickness of the bracket.
REVERSING THE HARDWARE
4
4.1 Move the bottom hinge bracket and plastic washer from
the right side to the left side.
Switch the hinge pin to the
opposite side of the bracket.
(CONT.)
Plastic
Washer
Hinge
Bracket
