System Map: Front, Left, Right & Rear Views (Model A)
1
2
12 13
10 11
Figure 7 - Front, Left, Right & Rear Views (Model A)
1. LED Indicators
2. DC-In Jack
3. RJ-45 LAN Jack
4. Mini DisplayPort 1.2
5. Mini DisplayPort 1.3
6. HDMI-Out Port
7. USB 3.1 Gen 2 Type-C Port
8. USB 3.1 Gen 2 Type-A Port
14
Front
Left
7
6
3
4
5
Right
14
Rear
9. Multi-in-1 Card Reader
10. Headphone-Out Jack
11. Microphone-In Jack
12. USB 2.0 Port
13. USB 3.0 (USB 3.1 Gen 1)
Type-A Port
14. Vent
15. Security Lock Slot
9
8
15
14

Mini DisplayPorts
External displays can be config-
ured either using the Intel®
UHD Graphics Control Panel
or by the Project menu (press
+ P or Fn + F7).
If you wish to configure an exter-
nal display connected to Mini
5
DisplayPort 1.3 you must
use Project menu to control the
display configuration.
Overheating
To prevent your computer from
overheating make sure nothing
blocks any vent while the com-
puter is in use.
