SPECIFICATIONS
Model Number:
LDU3047IEMT
Product Type:
In-Ear Monitoring
Type:
Transmitter
Transmission frequency
470 - 490 MHz
range:
RF-Channels:
12
Transmission method:
FM, mono/stereo
Rated HF output power:
10 mW
Antenna gain:
2.15 dBi
Antenna
BNC
connector:
Audio Frequency
50 Hz – 16000 Hz
response +/- 1,5dB:
THD+N @ 1kHz:
< 0.5%
S/N –Ratio @ 1kHz,
90 dB
A-weighted:
Dynamic range @ 1kHz,
88 dB
non-weighted:
Input Sensitivity:
-4.5 dBu (all gain
controls full, stereo
mode)
Max. Input Level:
+15dBu (all gain
controls set to 9
o´clock, stereo
mode)
CMRR IEC:
45 dB
Line inputs:
2
Line input
XLR (balanced) /
connectors:
Combo TRS 6.3 mm
Input impedance:
8.5 k ohms
Controls:
Input level L + R
controls, mono/ste-
reo –switch, power
on-off -button
Indicators:
2 Digit backlit
LC-display (channel
number), 2x 5
segment LED VU
Meter
Power
1.7 W
Consumption (nominal):
Operating Voltage:
12 - 18 V DC
Voltage input connector:
5.3 mm barrel jack,
plus inside
Ambient
0°C - 35°C
Temperature
(in operation):
Relative Humidity:
<80%
(non-condensing)
8
LDU3051IEMT
LDU305IEMT
In-Ear Monitoring
In-Ear Monitoring
Transmitter
Transmitter
514 - 542 MHz
584 - 608 MHz
12
12
FM, mono/stereo
FM, mono/stereo
10 mW
10 mW
2.15 dBi
2.15 dBi
BNC
BNC
50 Hz – 16000 Hz
50 Hz – 16000 Hz
< 0.5%
< 0.5%
90 dB
90 dB
88 dB
88 dB
-4.5 dBu (all gain
-4.5 dBu (all gain
controls full, stereo
controls full, stereo
mode)
mode)
+15dBu (all gain
+15dBu (all gain
controls set to 9
controls set to 9
o´clock, stereo
o´clock, stereo
mode)
mode)
45 dB
45 dB
2
2
XLR (balanced) /
XLR (balanced) /
Combo TRS 6.3 mm
Combo TRS 6.3 mm
8.5 k ohms
8.5 k ohms
Input level L + R
Input level L + R
controls, mono/ste-
controls, mono/ste-
reo –switch, power
reo –switch, power
on-off -button
on-off -button
2 Digit backlit
2 Digit backlit
LC-display (channel
LC-display (channel
number), 2x 5
number), 2x 5
segment LED VU
segment LED VU
Meter
Meter
1.7 W
1.7 W
12 - 18 V DC
12 - 18 V DC
5.3 mm barrel jack,
5.3 mm barrel jack,
plus inside
plus inside
0°C - 35°C
0°C - 35°C
<80%
<80%
(non-condensing)
(non-condensing)
LDU306IEMT
LDU308IEMT
In-Ear Monitoring
In-Ear Monitoring
Transmitter
Transmitter
655 - 679 MHz
823 - 832 MHz &
863 - 865 MHz
12
12
FM, mono/stereo
FM, mono/stereo
10 mW
10 mW
2.15 dBi
2.15 dBi
BNC
BNC
50 Hz – 16000 Hz
50 Hz – 16000 Hz
< 0.5%
< 0.5%
90 dB
90 dB
88 dB
88 dB
-4.5 dBu (all gain
-4.5 dBu (all gain
controls full, stereo
controls full, stereo
mode)
mode)
+15dBu (all gain
+15dBu (all gain
controls set to 9
controls set to 9
o´clock, stereo
o´clock, stereo
mode)
mode)
45 dB
45 dB
2
2
XLR (balanced) /
XLR (balanced) /
Combo TRS 6.3 mm
Combo TRS 6.3 mm
8.5 k ohms
8.5 k ohms
Input level L + R
Input level L + R
controls, mono/ste-
controls, mono/ste-
reo –switch, power
reo –switch, power
on-off -button
on-off -button
2 Digit backlit
2 Digit backlit
LC-display (channel
LC-display (channel
number), 2x 5
number), 2x 5
segment LED VU
segment LED VU
Meter
Meter
1.7 W
1.7 W
12 - 18 V DC
12 - 18 V DC
5.3 mm barrel jack,
5.3 mm barrel jack,
plus inside
plus inside
0°C - 35°C
0°C - 35°C
<80%
<80%
(non-condensing)
(non-condensing)
