INSTRUCTIONS FOR USE
Brush overload safety system activation
7. In case of brush motor overload, due to foreign bodies
which prevent the brushes/pad-holders from rotating, or
to excessively aggressive floors/brushes, the safety
system stops the brushes/pad-holders after about a
minute of continuous overload. The overload is shown
by the three warning lights (9a, 9b, 9c, Fig. B) flashing
simultaneously.
If the overload takes place during a cleaning with the
extra pressure function activated, the system
automatically reduces the pressure on the
brushes/pad-holders deactivating the extra pressure
function. If the overload persists, the
brushes/pad-holders stop.
8. To start again after the brushes/pad-holders stop due to
overload, reset the machine by turning the ignition key
(10, Fig. B) to "0" position; then restart the machine by
turning the ignition key to "I" position.
Battery discharge during operation
9. Until the green warning light (9a, Fig. B) stays on, the
batteries allow the machine to work normally.
When the green warning light (9a) turns off and first the
yellow warning light (9b) and then the red warning light
(9c) turn on, it is necessary to charge the battery,
because the machine residual autonomy of operation is
the following:
– When the yellow warning light (9b) turns on the
machine residual autonomy will last for a few
minutes (depending on the characteristics of the
battery).
– When the red warning light (9c) turns on the machine
autonomy is over: after a few seconds
brushes/pad-holders are automatically stopped and
the deck is automatically lifted; the squeegee
vacuuming and the machine drive still operate, just to
dry the wet floor and move the machine to the
charging area.
CAUTION!
Do not use the machine with discharged
batteries, to avoid damaging the batteries and
reducing the battery life.
NOTE
In case the machine drive cannot be used in
order to move the machine, see the
Pushing/Towing The Machine paragraph.
10 Razor™ Plus 24D-26D-28D / Razor™ Plus 24C-28C — 909 5428 000(2)2005-01
Recovery water recirculation function (optional)
10. If equipped, turn the switch (35, Fig. C) to "I" position to
activate the recovery water recirculation function.
This function allows the recovery water collected in the
tank (5, Fig. G), once it has been adequately
regenerated by passing through the filter (8, Fig. G), to
be used together with the clean solution in the tank (4,
Fig. G).
CAUTION!
Do not activate the recovery water
recirculation function when cleaning special
areas where a particular thorough hygiene is
required (hospitals, schools, etc.)
The recovery water recirculation function can
be very useful when cleaning industrial areas,
etc.
NOTE
The recovery water recirculation function
switch (35, Fig. C) can be activated and
deactivated in any moment, but note that the
recovery water recirculation system starts
operating only when the tank (5, Fig. G)
contains at least 60 liters of water (tank filled
up to 3/4).
11. If equipped, turn the switch (35, Fig. C) to "0" position to
deactivate the recovery water recirculation function. The
machine restarts to operate normally, using only the
clean solution in the tank (4, Fig. G).

TANK EMPTYING

An automatic float shut-off system (7, Fig. G) deactivates the
vacuum system once the recovery tank (5) is full.
The vacuum system deactivation is signalled by a sudden
increase in the vacuum motor noise frequency. The vacuum
motor stops automatically after a few seconds.
CAUTION!
If the vacuum motor stops accidentally (for
example, because of the float interference due
to a sudden movement of the machine), to
restart the vacuum system, lift the squeegee
(16, Fig. C) by means of the lever (25) and then
lower it.
When the recovery water tank (5, Fig. G) is full, empty it
according to the following procedure.
