INSTRUCTIONS FOR USE

BEFORE MACHINE START-UP

WARNING!
When the machine is to be started by turning
the ignition key (10, Fig. B) to "I" position,
make sure that, between the deck (12 or 15, Fig.
C) and the above tank assembly, there is no
foreign material which may prevent the deck
from lifting. This check is necessary because,
if the machine has been previously turned off
without the deck being deactivated (lifted
position), when turned on again, the deck is
automatically deactivated (lifted position).

DECK INSTALLATION/REPLACEMENT

On the machines from Serial Number 1776829, it is possible
to install either a brush-holder/pad-holder deck (12, Fig. C) or
a cylindrical brush-holder deck (15).
For deck installation/replacement see the procedure in the
Maintenance chapter.
Brush or pad-holder installation/replacement
1. According to the kind of cleaning to be carried out, the
machine can be equipped both with brushes (15, Fig. J)
and pad-holders (16) with pads(17) together with the
appropriate deck.
2. Insert the ignition key (10, Fig. B) and turn it to "I"
position.
WARNING!
Before turning on the brush/pad-holder deck
lifting/lowering switch (2, Fig. B), always check
that, between the deck (12) and the above tank
assembly, there is no foreign material which
may prevent the deck from lifting.
3. Idle the speed adjuster (7, Fig. B) by turning it
counter-clockwise.
4. Position the brushes/pad-holders under the appropriate
deck (12, Fig. C).
5. Press the switch (2, Fig. B) to lower the deck (12, Fig. C).
6. Lightly press the paddle (4, Fig. C) to engage the
brushes.
WARNING!
Do not press the paddle (4, Fig. C) completely,
otherwise the machine will start; a light
pressure on the paddle is enough to engage
the brushes and activate the brush motors.
7. Press the switch (2, Fig. B) to deactivate the deck (12,
Fig. C) (lifted position).
WARNING!
When the deck has not been lifted yet, and the
warning light on the switch (2, Fig. B) is
flashing, the brushes (11, Fig. C) start to turn
when pressing the paddle (4, Fig. C). It is
therefore important to make sure that there is
nothing which can prevent the brush from
rotating and that nobody is near the brushes
before pressing the paddle (4, Fig. C).
8. Turn the ignition key (10, Fig. B) to "0" position and
remove it.
8 Razor™ Plus 24D-26D-28D / Razor™ Plus 24C-28C — 909 5428 000(2)2005-01
Cylindrical brush installation
9. Insert the ignition key (10, Fig. B) and turn it to "I"
position.
10. Turn on the cylindrical brush-holder deck lifting/lowering
switch (2, Fig. B).
WARNING!
Before turning on the cylindrical brush-holder
deck lifting/lowering switch (2, Fig. B), always
check that, between the deck (15) and the
above tank assembly, there is no foreign
material which may prevent the deck from
lifting.
11. Turn the ignition key (10, Fig. B) to "0" position and
remove it.
12. Unscrew the handwheels (25, Fig. J) and remove the
lids (24) by pushing them downwards and pressing on
the handwheels.
13. Install the cylindrical brushes (23).
The cylindrical brushes can be installed on either sides.
14. Reinstall the lids (24, Fig. J) and fix them with the
handwheels (25).
Squeegee installation
15. Install the squeegee (16, Fig. C) and fix it by means of
the handwheels (17), then connect the hose (24) to the
squeegee.
16. Using the handwheel (18, Fig. C), adjust the squeegee
so that its rear blade (20) - in all its length - touches the
floor and that the front blade (19) is slightly detached
from the floor.
Solution tank filling
17. Open the tank cover (1, Fig. G).
18. Lift the shield (15, Fig. G) and, by means of the
extractible hose (6), fill the solution tank (4) with the
appropriate solution for the cleaning to be carried out.
Do not fill the solution tank completely, leave a few
centimeters from the edge.
Always follow the dilution instructions on the label of the
chemical product used to create the solution.
The solution temperature must not exceed 104°F
(40°C).
Using the transparent hose (1, Fig. J) and the marks (2),
it is possible to check the quantity of solution in the tank.
Moreover, it is possible to consult a gallon/liter table
located on the inner side of the cover (1, Fig. G).
CAUTION!
Use only low-foam and non-flammable
solutions, intended for automatic scrubber
applications.
Adjustments
19. Using the knobs (3, Fig. C), adjust the handlebar (2) to
reach a comfortable position.
