Measurement table (in °C):
Designation Ear / forehead
Subnormal temperature < 35.7
Normal temperature 35.8 – 36.9
Elevated temperature 37.0 – 37.5
Slight fever 37.6 – 38.0
Moderate fever 38.1 – 38.5
High fever 38.6 – 39.4
Very high fever 39.5 – 42.0
The measurement in the ear and on the forehead can produce different results as the forehead
temperature depends more on external influences than the temperature in the eardrum.
The forehead measurement depends on external influence more than rectal, oral or axillary
measurements.
In case of several measurements after each other, slightly varying results are measured within the
range of the measuring error tolerance as a rule.
Measurement site
Anus Mouth / armpit
< 36.2 < 35.8
36.3 – 37.4 35.9 – 37.0
37.5 – 38.0 37.1 – 37.5
38.1 – 38.5 37.6 – 38.0
38.6 – 39.0 38.1 – 38.5
39.1 – 39.9 38.6 – 39.5
40.0 – 42.5 39.6 – 42.0

5. Safety precautions

This device may be used only for the measurement of human body temperature in the ear and on
the forehead. The manufacturer shall not be held liable for any damage resulting from improper
handling.
Do not leave the device unattended near toddlers or persons who cannot operate it themselves.
Do not expose the device to hard knocks or vibrations. Do not use the device, if you notice any
kind of damage.
Prior to every measurement, please check whether the glass lens of the sensor is clean, free from
grease, and is not damaged.
Please observe the storage and operating conditions mentioned in Chapter 14 "Technical data".
Protect the device against dirt and dust, extreme temperatures, solar radiation and fluids.
For cleaning, please follow the instructions mentioned in Chapter 8 "Cleaning and maintenance
of the device".
The device must not be altered, dismantled or repaired by the user.
The use does not replace medical treatment in any way.
If you inform your doctor about the temperature measured, please also mention that this
temperature has been determined in the ear or on the forehead.

6. Initial operation of the device

Batteries are included in the scope of delivery and have been placed in the device already. However,
