TECHNICAL DATA

Press device
Production code
Battery voltage
Power consumption
Nominal force
Compression range :
Ø Plastics & Composite pipes
Ø Metal until
Weight according EPTA-Procedure 01/2003
(Li-lon 2,0 Ah)
Weight
(M18 BLHPT / Li-Ion 2.0 Ah / J18-Th14)
Noise information
Measured values determined according to EN 60745. Typically, the
A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty K=3dB(A))
GB
Sound power level (Uncertainty K=3dB(A))
Wear ear protectors!
Vibration information
Vibration total values (triaxial vector sum) determined according
to EN 60745
Vibration emission valuea
Uncertainty K=
WARNING!
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN 60745
and may be used to compare one tool with another. It may be used
for a preliminary assessment of exposure.
The declared vibration emission level represents the main
applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the
vibration emission may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration should also take
into account the times when the tool is switched off or when it is
running but not actually doing the job. This may significantly reduce
the exposure level over the total working period.
Identify additional safety measures to protect the operator from the
effects of vibration such as: maintain the tool and the accessories,
keep the hands warm, organisation of work patterns.
WARNING! Read all safety warnings and all instruc-
tions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury. Save all warnings and
instructions for future reference.
PRESS DEVICE SAFETY WARNINGS
Use protective equipment. Always wear safety glasses when
working with the machine. The use of protective clothing is recom-
mended, such as dust mask, protective gloves, sturdy non-slip
footwear, helmet and ear defenders.
Never hold your fingers or other body parts in the working area of
the cylinder or the press jaws.
Do not hold the jaw levers with your hands during the pressing
operation.
Press tools and press devices may only be used by trained
personnel.
English Deutsch
12
M18 BLHPT
4524 10 02 ...
... 000001-999999
18 V
450 W
32 kN
63 mm (110 mm)
54 mm (108 mm)
dep. on system
2,9 kg
4,7 kg
76,5 dB (A)
87,5 dB (A)
<2,5 m/s
h
1,5 m/s
2
Check the press tools and press devices for cracks and other signs of
wear before each use.
Only use press tools and press devices that are in perfect technical
condition.
Have damage repared immediately by an authorised workshop.
The machine may only be used with a press jaw inserted into it.
In the event of problems during the pressing process, press the
Emergency Stop button immediately and release the ON switch.
The valve will open and the piston will return to its initial position.
Compliance with the specified service work and service intervals is
mandatory.
Remove the battery pack before starting any work on the
appliance.

WORKING INSTRUCTIONS

Use only system-compatible press fittings and press jaws designed
for them.
Consult the documents provided by the system supplier for hand-
ling and assembly instructions for fittings and pipes.
Check whether the nominal width of the press fitting corresponds
to the nominal width of the press jaws.
Make sure that the press jaw is fully closed when pressing is
complete.
Imperfect pipe joints must be compressed again using a new
fitting.
After finishing the work, check the installation with appropriate
2
testing equipment and assure that it is leakproof!
The press device is not suitable for continuous operation. Following
30 minutes of continuous operation, a short break of at least 15
minutes must be taken to allow the device to cool down.

SPECIFIED CONDITIONS OF USE

The devices and the press jaws are designed exclusively for the
press-fitting of pipes and fittings for which the relevant press jaws
are intended.
These press devices are intended exclusively for use with press jaws
approved by Milwaukee in agreement with the system supplier.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of
the battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully
charged, after use.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days: Store the battery
pack where the temperature is below 27°C and away from moisture
Store the battery packs in a 30% - 50% charged condition Every six
months of storage, charge the pack as normal.
Do not dispose of used battery packs in the household refuse or
by burning them. Milwaukee Distributors offer to retrieve old
batteries to protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System C18 chargers for charging System C18 battery
packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
