OPERATION
GB
RECEIVER CONFIGURATION
WARNING: during the entire confi guration phase, the receiver's relays are not active.
WARNING: during the entire confi guration phase of the receiver, the ON/OFF LED will remain off.
Press the confi guration button to enter the receiver's confi guration menu. The dot on the display lights up to
show that it has been pressed.
Press the confi guration button and keep it pressed; the external segments of the display will light up in rapid
clockwise succession and will then show the letter
tion button.
By quickly pressing and releasing the confi guration button the next item in the menu can be selected (see
confi guration menu table).
Confi guration menu table
DISPLAY DESCRIPTION
Programming without translation
Programming with translation
Filter function
Deleting receiver memory
Exiting the configuration menu
In order to confi rm the choice of the menu item, keep the confi guration button pressed until the chosen letter
fl ashes regularly.
Programming function (letter
This function allows to store the transmitter ID in the receiver's memory.
The relays will be programmed in sequence, button 1 of the transmitter will correspond to relay 1, button 2 will
correspond to relay 2, and so on.
Once letter has been selected (always on) keep the confi guration button pressed until the letter fl ashes con-
stantly. Release the confi guration button.
Press any key on the transmitter, the letter
stored in the receiver's memory.
If the transmitter key is pressed for more than 5 seconds, the receiver will exit programming status and go back
to a fi xed .
In sequence other transmitters can be programmed, up to a maximum of 50. Once 10 seconds have passed after
entering the programming function or receiving the last valid ID, the receiver will exit programming status and go
back to letter constantly on. It is also possible to exit this function by pressing and releasing the button.
Programming function with translation (letter
Besides storing transmitter ID into the receiver's memory, this function allows to translate the sequence of
active relays based on the button pressed. This function allows to use a single transmitter to control multiple
receivers placed in different spots.
Once letter has been selected (always on) keep the confi guration button pressed until the letter
constantly. Release the confi guration button.
Press the key on the transmitter that has to be matched with relay 1. The letter
that the transmitter ID has been entered in the receiver's memory.
If the transmitter key is pressed for more than 5 seconds, the receiver will exit confi guration status and go back
to a fi xed .
In sequence other transmitters can be programmed, up to a maximum of 50. Once 10 seconds have passed after
entering the programming function or receiving the last valid ID, the receiver will exit programming status and go
back to letter constantly on. It is also possible to exit this function by pressing and releasing the button.
8
of the fi rst menu item steadily on. Release the confi gura-
)
will start fl ashing quickly to confi rm that transmitter ID has been
)
fl ashes
will fl ash quickly and confi rm
