CONNECTIONS, CONTROLS AND INDICATORS:
1
POWER LED
Lights up once the system is properly connected to the power mains and switched on (suitable power adapter included).
2
ANTENNA LEDS A / B
Indicate whether aerial input A or B is active.
3
NORM LED
Lights up as soon as an audio signal is present.
4
PEAK LED
Lights up if the receiver is operating at the distortion limit. To avoid distortion, reduce the signal level of the
transmitter unit.
Handheld Transmitter: Turn the GAIN knob with a suitable tool to the left.
Pocket Transmitter: 3-stage MIC / 0 dB / -10 dB switch, set to the next lowest value.
5
VOLUME
Volume controller of the receiver. Turning the knob to the right increases the volume and turning it to the left
decreases it.
6
AF OUTPUT
Balanced line output with XLR socket.
7
LOW VOLTAGE CONNECTOR
Connection for the voltage supply of the device. Please only use the power adapter included in the product package.
8
MUTE LEVEL
CAUTION: Before changing the Mute level, adjust the volume of the connected PA system to minimum.
The Mute function (noise reduction / Squelch) prevents any interference with the transmitter. In addition, sudden
noise is suppressed when the transmitted signal from the transmitter to the receiver is not strong enough.
With the transmitter switched off, adjust the Mute level with a suitable screwdriver so that noises are effectively
suppressed (when turned to the left, the noise reduction decreases, when turned to the right, it increases).
In unfavourable conditions, the transmission range may decrease when adjusting for strong noise reduction.
The Mute level controller is set to the left at the factory, therefore, the noise reduction is set at minimum strength.
This setting is suitable for the majority of applications and changes are only needed in rare cases.
9
UNBAL OUTPUT
Unbalanced line output with 6.3 mm jack.
