Type Voltage / Frequency
230 VAC
729 x00 68
(115-230 VAC 50/60 Hz)
729 120 55
729 320 55
729 220 55 24 VDC (0 Hz)
729 420 55
729 520 55
230 VAC
729 x20 60 (115 VAC 50/60 Hz -
230 VAC 50 Hz)
729 150 55
729 350 55
24 VDC (0 Hz)
729 250 55
729 450 55
729 550 55
230 VAC
729 x50 60 (115 VAC 50/60 Hz -
230 VAC 50 Hz)
729 160 55
729 360 55
24V DC (0 Hz)
729 260 55
729 460 55
729 560 55
230 VAC
729 x60 60 (115 VAC 50/60 Hz -
230 VAC 50 Hz)
785 x00 75 24 VAC/DC 0/50/60 Hz
115-230 VAC/DC
785 x00 70
0/50/60 Hz
7

Mounting

For dimensions and mounting see "Zeichnungen / Drawings / Dessins" page 22
et seq.
If required, a wire guard can be screwed on (accessory).
(see fig. 8 page 25)
7.1 Opening of the Ex d housing
Caution
• Do not open the light fitting under a live voltage!
• After disconnecting the power, observe the prescribed waiting time before
opening it.
• Power is only to be switched on when the housing is closed and it has been
ensured that all explosion protection measures have been taken.
12
Lamp Current consumption
LED 0.03 A
<0.17 A
LED
<0.12 A
0.07 A (115 V~)
LED
0.15 A (230 V~)
<0.14 A
LED
<0.09 A
0.07 A (115 V~) 0.14
LED
A (230 V~)
<0.24 A
LED
<0.15 A
0.07 A (115 V~) 0.14
LED
A (230 V~)
24 V /
1 A
20 W
12 V / 0.35 A (115 V~) 0.13
20W A (230 V~)
Power T class Surface
consump- temp.
tion.
1.3 W T6 80 °C
3.6 W
T6 80 °C
2.6 W
1.1 W
(115 V)
T5 95°C
3.6 W
(230 V)
1 W
T6 80 °C
0.7 W
1.3 W
(115 V)
T5 95 °C
3.8 W
(230 V)
2.8 W
T6 80 °C
1.9 W
1.3 W
(115V)
T5 95°C
3.8 W
(230V)
22 W T5 95 °C
22 W T5 95 °C
