Madel ZONING SYSTEM Manuel D'utilisation page 20

• Locating thermostats
• Battery change
• Troubleshooting
• Zoning operation with Crono-TM/TZ-TEMP thermostats
• Zoning operation with KARESS touch-screen thermostats
TECHNICAL CHARACTERISTICS:
Control board (receiver)
Power: 230 VAC, 50/60 Hz.
Consumption: 10 VA
Average scope: 50 m in free field. 20 m in the habitat.
External aiming antena.
Size (mm): 160 x 90 x 60
Carrier frequency (ISM Band, as per I-ETS 300-220
standard): 433.92 MHz (Optional: 434.33 MHz)
Operating cycle <10%
Recieverr. Class III
Protection level: IP 20
Electric shock insulation Clase II.
Operating temperature: 0 ºC a 55ºC.
Storage temperature:: -10 ºC a 60 ºC.
Hereby MADEL ATD decalres that the Zoning system (control board + thermostats) is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/CE.
KRCPLUS:
User's manual [GB]
V12/08
Thermostat (transmiter)
Power: 2 x 1.5 V LR06 AA batteries (supplied).
Average autonomy 1 year (or more).
Battery wear indicator.
Carrier frequency (ISM Band, as per I-ETS 300-220
standard): 433.92 MHz (Optional: 434.33 MHz)
Average scope: 50 m in free field. 20 m in the habitat.
Size (mm) (mm): 112 x 71 x 19.
Operating temperature: 0 ºC a 55ºC.
Storage temperature:: -10 ºC a 60 ºC..
Wall attachment using screws (supplied)
Protection level: IP 20
ECO mode (ordered temp. variation of ± 3ºC)
