AS-XP
Filter dimensions ....................................110 x 90 x 9 mm
Vision area ..................................................... 92 x 42 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state ................................9/13
Degree of protection for grinding ....................................2
Protection against inferred and ultraviolet ....................16
Interval between clear to dark ...................... 1/25000 sec
Internal between dark to clear ........................ 0.2/0.8 sec
Sensibility. ............................................................. manual
Power supply ....................................................solar cells
Operating Temperature .......................................-5 -55 ºC
Weight .............................................................500 grams
Guarantee............................................................. 2 years
AS-X
Filter dimensions ....................................110 x 90 x 9 mm
Vision area ..................................................... 92 x 42 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state ................................9/13
Degree of protection at max dark state ........................13
Protection against inferred and ultraviolet ....................16
Interval between clear to dark ...................... 1/25000 sec
Internal between dark to clear ........................ 0.2/0.8 sec
Filter battery................................................Mod. CR2032
Sensibility. ............................................................. manual
Power supply ....................................................solar cells
Operating Temperature .......................................-5 -55 ºC
Weight .............................................................500 grams
Guarantee............................................................. 2 years
Process
Coated electrodes
MAG
TIG
MIG with heavy
Metals
MIG with light
Alloys
Finish-to-air arc
Plasma
Jet cutting
Micro plasma
Arc welding
NOTE – The tern "heavy materials" applies to steel, alloy steel, copper and its alloys, etc..
ENGLISH
Recommended use of different degrees of protection to EN 169 arc welding
30
40
60
70 100 125 150 175 200 225 250 300 350 400 450 500 600
9
10
9
10
9
10
9
9
10
9
30
40
60
70 100 125 150 175 200 225 250 300 350 400 450 500 600
19
AS-XL
Filter dimensions ....................................110 x 90 x 9 mm
Vision area ..................................................... 92 x 42 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state............................5/9-9/13
Protection against inferred and ultraviolet ....................16
Interval between clear to dark ...................... 1/25000 sec
Internal between dark to clear ........................ 0.2/0.8 sec
Sensibility. ............................................................. manual
Power supply ....................................................solar cells
Operating Temperature .......................................-5 -55 ºC
Weight .............................................................440 grams
Guarantee............................................................. 2 years
AS-R
Filter dimensions ....................................110 x 90 x 8 mm
Vision area ..................................................... 92 x 35 mm
Degree of protection, clear state ....................................4
Degree of protection, dark state ................................9/13
Protection against inferred and ultraviolet ....................15
Interval between clear to dark ..................... 1/20.000 sec
Internal between dark to clear .............................. 0.4 sec
Sensibility. ............................................................. manual
Power supply ....................................................solar cells
Operating Temperature .......................................-5 -55 ºC
Weight .............................................................500 grams
Guarantee............................................................. 2 years
6. USER INSTUCTIONS
6.1. Adjusting the mask to the user.
In the models AS-X / AS-XP / AS-1C. Adjustments may
vary do to different sizes of users head. To correctly adjust
the equipment to individual users, follow the proceeding
instructions.
Current intensity (A)
11
12
11
12
11
12
10
11
12
10
11
12
10
11
12
13
11
12
10
11
12
19
13
13
13
13
13
13
