2.4.3 Assign DMX channels to the controls of the console:

It is useful to assign DMX channels to the fixtures of the surface structure so that the surface layout can perform
the built-in movements, color effects and fading effects correctly. For example, For controlling the pan / tilt function
of a moving head, the corresponding DMX channels must be assigned to the pan and tilt wheel. For the control of
RGBWA + UV spotlights, the DMX channels that control red, green, blue, white, amber, UV and the dimmer
function must be assigned to the sliders 1-7.
1. Press and hold the / MENUS / key until the display shows 01. Patch fixture.
2. Press the / ENTER / -Key. The display shows "PLEAS SELECT FIXTURE"
3. Use / FIXTURE / -Keyn to select the first spotlight that has a DMX start address
(LED is lit). The display shows: e.g.
DMX START ADDR
FIX:01 ADR:001
4. Use the / SWAP / -Key to select "FADER CHANL". The display shows: e.g.
Fader CHANL: 1/D
DMX channel: 001
5. Use the Pan wheel to adjust the control (eg 1 / D dimmer, 2 / R color red, 3 / G color green, 4 / B color blue, 5 /
W color white, and Sw to PAN and TILT).
Use the tilt wheel to adjust the DMX channel of the headlight. (For this you need the DMX protocol of the
headlamp). Press the / ENTER / - key each time to save the settings. To confirm the operation, all the LEDs on the
controller flash three times.
Note: These function channels are fixed in the console and must therefore be correctly assigned. When a
headlamp, For example, no color mixing, channels 2 / R, 3 / G, 4 / B, 5 / W, 6 / A, 7 / UV should also be set to
NULL. Otherwise, you will not get useful results when using color effects.
6. To exit the system settings and save your settings, press and hold the / MENU / -Key again for 2 seconds

2.4.4 Assign a fog machine:

The console can control a DMX fog machine. This configures the machine.
1. Call the menu item "10. Fog machine control ". (See section 2.4.1 Menu structure)
2. Use the Pan dial to select "Auto FOG [OFF]" and "Auto FOG [ON]". When "Auto FOG" is set to OFF, the fog
machine is manually activated with the / DMX FOG / -Key. When "Auto FOG" is set to ON, the fog machine is
automatically activated with the internal timer.
3. To set the timer mode, press the / swap / key. The display shows: e.g.
ON TIME: 010S
OFF TIMER: 010S
4. Use the Pan wheel to set the Nebeldauer. (1 to 600 seconds)
Use the tilt wheel to set the time intervals between the fog emitted. (1 to 600 seconds)
Confirm your settings with ENTER
5. Press / SWAP / -Key to set the first control channel of the fog machine. The display shows: e.g.
FOG CH 1: Empry
VALUE: 255
Use the Pan wheel to set the DMX address. (1 to 512)
Use the Tilt dial to set the DMX value. (0-255)
Confirm your settings with ENTER.
