GB

10. Emptying the grass basket

As soon as grass clippings start to trail the lawn
mower, it is time to empty the grass basket.
Important! Before taking off the grass basket,
switch off the engine and wait until the blade has
come to a stop.
To take off the grass basket, use one hand to lift up
the chute flap and the other to grab onto the basket
handle (Fig. 4). Remove the basket.
For safety reasons, the chute flap automatically falls
down after removing the grass basket and closes off
the rear chute opening. If any grass remains in the
opening, it will be easier to restart the engine if you
pull the mower back approx. 1 meter.
Do not use your hands or feet to remove clippings in
or on the mower housing, but instead use suitable
tools such as a brush or a hand broom.
In order to ensure that the majority of grass clippings
are picked up, the inside of both the catch bag and
especially the air grill must be cleaned after each
use.
Reattach the catch bag only when the engine is
switched off and the blade is stopped.
Using one hand, lift up the chute flap, while grabbing
onto the basket handle with the other. Hang in the
basket from the top.

11. After mowing

1. Allow the engine to cool before you put the lawn
mower in an enclosed area.
2. Remove grass, foliage, grease and oil before
storing the mower. Do not place any objects on
top of the mower.
3. Check all the screws and nuts once more before
you start to use the lawn mower again. Tighten
any loose screws.
4. Also be sure to empty the grass basket.
5. Pull the spark plug boot to prevent unauthorized
use.
6. Ensure that you do not park the mower next to
any source of danger. Petrol fumes can lead to
explosions.
7. Only original parts or parts approved by the
manufacturer may be used for repairs
(see address on the warranty certificate).
8. If the lawn mower is not going to be used for an
extended period, empty the petrol tank using a
24
05.09.2007 14:23 Uhr Seite 24
petrol suction pump.
9. Tell your children not to use the mower. It is not
a toy.
10. Never place petrol near an ignition source.
Always use a can that is approved to store
petrol. Keep petrol away from children.
11. Oil and maintain the machine.
12. How to switch off the engine:
All you have to do to switch off the engine is
release the engine start/stop lever (Fig.
5a/Item A). Close the petrol cock and pull the
spark plug boot from the spark plug boot in order
to prevent the engine from restarting. Before you
start the engine again, check the cord for the
engine brake. Check that the cord is correctly
fitted. If the cord is kinked or damaged, it should
be replaced.

12. Care and maintenance

Important:
Never work on or touch conducting parts on the
ignition unit with the engine running. Always pull the
spark plug boot from the spark plug before starting
any work of care or maintenance. Never perform any
work on the machine while it is running. Any work not
described in these Operating Instructions must be
performed by an authorized service workshop only.

12.1. Cleaning the lawn mower

The lawn mower should be thoroughly cleaned after
every use, especially the underneath and the blade
mount. To do so, tip the lawn mower onto its left side
(the opposite side to the oil filling socket).
Important: Before you tip the lawn mower onto its
side, completely empty the fuel tank using a petrol
suction pump. The lawn mower must never be tilted
by more than 90 degrees. Dirt and grass is easiest to
remove immediately after you have finished mowing
the grass. Dried on grass and dirt can result in
poorer mowing performance. Check that the grass
chute is free of any residual grass. Remove any such
residue. Never clean the lawn mower with a water jet
or high-pressure cleaner. The engine must remain
dry. Do not use aggressive cleaning agents such as
cold cleaner or petroleum ether.

12.2. Wheel axles and wheel hubs

These should be lightly greased once a season. To
do so, remove the wheel caps with a screwdriver and
slacken the fastening screws on the wheels.
