ENGLISH
INSTALLING THE BATTERIES IN THE REMOTE CONTROL
• Place the remote face down on a flat surface.
• Push the compartment cover into the direction of the arrow.
• Slide the battery compartment open.
• Remove the old battery and install the new one (CR2032) with the plus (+) symbol facing
up.
• Gently slide the battery compartment closed. It locks automatically.
RECOMMENDATIONS FOR BATTERIES
This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in ac-
cordance with your local regulations..
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
ATTENTION: Danger of explosion if battery is incorrectly placed. Only replace by the same or equivalent type.
WARNING :The supplied remote control contains a button cell. In case of ingestion, it might cause serious internal burns within
only 2 hours that might lead to death. Do not swallow the battery. Keep new and old batteries out of the reach of children.
If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of children.
If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact immedi-
ately a doctor.
SPECIFICATIONS
Output Power ..................................................................................................................................... 2 x 50W
Power supply ................................................................................................................... 220-240V~ 50/60Hz
Consumption ............................................................................................................................................ 50W
Bluetooth frequency band....................................................................................................... 2402-2480MHz
Max. RF emission ..............................................................................................................................3.62dBm
Frequency Response .................................................................................................................20 – 20000 Hz
Input Sensitivity ...................................................................................................................................400mV
Signal-Noise-Ratio (S/N) ..................................................................................................................... ≥ 76dB
Impedance ..................................................................................................................................................8Ω
Microphone Input Sensitivity .................................................................................................................. 20mV
Dimensions ....................................................................... Box: 100 x 80 x 170mm Amp: 160 x 115 x 50mm
Weight ....................................................................................................................................................... 1kg
©Copyright LOTRONIC 2024
5
