5. Change the refrigerator door:
1) Remove the cover plate of the upper end cover of the refrigeration door and the left decorative cover.
Install the upper shaft sleeve and the signal line terminal 1 of the door body to the other side and cover
the upper end cover plate. Take out the right decorative cover from the accessory bag and install it to
the other side of the upper end cover.
2) Remove the door self-locking, door stop and shaft sleeve of the refrigeration door, take out the
left door self-locking from the accessory bag, install it on the left side of the lower end cover of the
refrigeration door, change the door stop and shaft sleeve to the left side of the lower end cover of the
refrigeration door.
6. Change the freezing door:
1) Remove the shaft sleeve and cap of the upper end cover of the freezing door and install them at the
left and right swap positions.
2) Remove the door self-locking, door stop and shaft sleeve of the freezing door, take out the left door
self-locking from the accessory bag, install it on the left side of the lower end cover of the freezing door,
change the door stop and shaft sleeve to the left side of the lower end cover of the freezing door.
7. Install the replaced freezing door on the lower hinge, then install the middle hinge and cover the hinge
hole decorative cover.
decorative cover
middle hinge
