Levelling feet
L
The picture above is only for reference. The actual configuration will depend on the physical product or
statement by the distributor.
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
Door right-left change
Cross screwdriver
5/16''
socket and ralchet
SN
Part
1
Upper hinge
2
Upper hinge cover
3
Decorative cover
4
Door self-locking
5
Middle hinge
6
Decorative cover
7
Lower hinge
8
Levelling feet
9
Left upper hinge
10
Left upper hinge cover
11
Left door self-locking
12
Right plastic cover
H
List of lools to be provided by the user
Parts to be used for door reverse
Quantity
Pre-installed on refrigerator, removed and retained it when changing
1
the door
Pre-installed on refrigerator, removed and retained it when changing
1
the door
Pre-installed on refrigerator, removed and retained it when changing
1
the door
Pre-installed on refrigerator, removed and retained it when changing
2
the door
1
Pre-installed on the refrigerator and to be used when changing the door
1
Pre-installed on the refrigerator and to be used when changing the door
1
Pre-installed on the refrigerator and to be used when changing the door
1
Pre-installed on the refrigerator and to be used when changing the door
1
In the attached plastic bag, take them out for use when door is reversed
1
In the attached plastic bag, take them out for use when door is reversed
2
In the attached plastic bag, take them out for use when door is reversed
1
In the attached plastic bag, take them out for use when door is reversed
Putty knife
thin-blade screwdriver
Masking tape
Notes
5
ENG
