7.2.

Protocol

Serial transmission rate
Serial ports
Settings and configuration
Modes
Integrated protocol
Integrated profiles
Standards
Range
References
ARF33-PRO
• ARF7474KA - RS232/485 version integrated aerial
• ARF7474LA - RS232/485 version separate aerial
• ARF7474MA - USB version integrated aerial
• ARF7474NA - USB version separate aerial
ARF43-PRO
• ARF7474OA - RS232/485 version integrated aerial
• ARF7474PA - RS232/485 version separate aerial
• ARF7474QA - USB version integrated aerial
• ARF7474RA - USB version separate aerial
ARF53-PRO
• ARF7474SA - RS232/485 version integrated aerial
• ARF7474TA - RS232/485 version separate aerial
• ARF7474UA - USB version integrated aerial
• ARF7474VA - USB version separate aerial
Glossary
TBD to be defined
NC not connected
NU not used
FHSS Frequency Hopping Spread Spectrum
FIFO First In First Out
WB wide band
NB narrow band
208210A_UG_V1.0_ARFx3-PRO
600, 1200, 2400, 4800, 9600, 19200, 38400 and 57600
bauds (programmable via AT commands)
TxD, RxD, RTS, CTS. Standard configuration: RS232 port
RS485 configuration is carried out via AT commands
Via Hayes commands
Transparent or addressed and/or repeater mode
ADEUNIS RF enhanced versatile communications manager
Multimode modem with repeater characteristics
EN 300-220 and EN 301-489 (modems 100% certified)
from 200 metres to 6 km
