NOTE 3
(S200 register) cf page 10.
NOTE 4
The preamble length is linked to the current radio transmission rate.
Preamble values are:
wide band channel
(high radio transmission rate)
narrow band channel
(low radio transmission rate)
PLEASE NOTE
It should be borne in mind that reducing the default preamble length will reduce the transmission delay but risks
generating possible errors in the frame transmission rate (up to 1 or 2/1000)!
In the case of narrow band, it is not possible to set the preamble length below 10ms.
NOTE 5
When you change the serial link configuration (transmission rate, parity, stop bit...), the response is made with
the previous format of the serial link. It is the next command that will be sent using the new format of the serial
link.
7.

Specifications

7.1.

General technical characteristics

Operating temperature
Electricity power supply
Dimensions
Number of channels
Modulation
Case
Transmitter
Frequencies programmable
RF transmitted power programmable
Tx / Rx consumption
Receiver
Receiver sensitivity
Radio transmission rate
RSSI
208210A_UG_V1.0_ARFx3-PRO
The default preamble length The minimum preamble length
5 ms
20 ms
-30 to +70 °C
4.5 to 36 V (integrated regulator)
145 ´ 100 ´ 40 mm
2 WB channels and 65 NB channels
FSK
IP65 case with integrated or external aerial
from 863.05 to 869.60MHz
from 10 to 27dBm
3.2 W / 0.27 W
up to -112 dBm for BER 10-3
10kpbs and 57.6 kbps
accessible via AT commands
4 ms
10 ms
GB
43
